Hydronic Radiators

Zehnder
Roda

Hydronic operation

    Ideal for entrance halls, kitchens and bathrooms. Zehnder Roda takes up hardly any room. Actually it creates space! Useful accessories, such as hooks and towel rails, make the radiator Zehnder Roda even more practical Available in all colours and surfaces from the Zehnder colour chart.

    Hydronic Radiators

    Zehnder Roda - Hydronic operation

    We also offer the following technologies

    Electric operation

    Benefits

    • Wide range of elegant accessories for a variety of combination options
    • Wide range of models supports versatile use
    • Short response time means rooms can be heated up rapidly
    • High thermal output means large rooms are heated up rapidly

    Colour System

    Zehnder Roda - Hydronic operation
    Traffic White (9016* / RAL 9016)
    * These colours / surfaces are glossy, all others matt.
    Despite extreme care in the painting process of our radiators, slight colour deviations are possible, depending on the production series and compared to other colour carriers (ceramic, paper, metal, ...) as well as screen display.
    RAL and NCS are manufacturer's designations.

    Technical data

    Connection to hot water central heating system

    Horizontal models
    With horizontal elements
    Model H L Heat output
    75/65/20 °C 70/55/24 °C 55/45/24 °C 55/45/20 °C
    mm mm Watts Watts Watts Watts
    ROH60 592 1000 665 476 288 346
    H = height, L = length
    75/65/20 = Nominal heat output according to EN 442
    Horizontal models
    With vertical elements
    Model H L Heat output
    75/65/20 °C 70/55/24 °C 55/45/24 °C 55/45/20 °C
    mm mm Watts Watts Watts Watts
    ROHD60 592 1000 1069 769 469 562
    H = height, L = length
    75/65/20 = Nominal heat output according to EN 442
    Horizontal models
    With vertical elements
    Model H L Heat output
    75/65/20 °C 70/55/24 °C 55/45/24 °C 55/45/20 °C
    mm mm Watts Watts Watts Watts
    ROHL-060/030 592 1000 1003 712 426 514
    ROHL-060/044 592 1000 1005 725 444 531
    ROHL-060/060 592 1000 1074 773 471 564
    H = height, L = length
    75/65/20 = Nominal heat output according to EN 442
    Vertical models
    Model H Heat output
    75/65/20 °C 70/55/24 °C 55/45/24 °C 55/45/20 °C
    mm Watts Watts Watts Watts
    ROV180 1800 142 101 60 72.7
    H = height, L = length
    75/65/20 = Nominal heat output according to EN 442
    Vertical models
    Model H Heat output
    75/65/20 °C 70/55/24 °C 55/45/24 °C 55/45/20 °C
    mm Watts Watts Watts Watts
    ROVD180 1800 206 146 87 105
    H = height, L = length
    75/65/20 = Nominal heat output according to EN 442
